ALED Series

Home
Products

ALED Series

Energy-saving Dual Chip
True-to-original Color Expression
6000Hz Ultra-high Refresh Rate
High-quality Gray Scale
Download Product Description

  • Energy-saving dual IC

    Use dynamic energy-saving dual PWM-SS ICs to support 4.5V low voltage and dynamic standby to save more energy.

  • Clear screen without syringe

    6000Hz ultra-high refresh rate for comfortable viewing and clear screen without syringe.

  • High Quality Gray Scale

    Reducing the brightness does not destroy the contrast difference and creates a deeper picture.

  • True-to-original Color Expression

    Through strict selection of each element and uniform wavelength and placement, a high-quality screen is displayed, allowing you to enjoy the colors of the content without distortion.

  • Front and Rear Maintenance

    Easy maintenance from all directions, front and back.

Specification

SMD Module
This table provides specifications for AVAVISION's ALED display, including model name, pixel pitch (mm), pixel configuration, module size (WxHxD), module resolution, cabinet resolution, refresh rate (Hz), viewing angle (H/V), and power consumption (Max/Avg)(W).
Model Name ALED-GS12 ALED-GS15 ALED-GS18 ALED-GS20 ALED-GS25
Identifier 25652215 25652217 25652218 25652219 25652220
Cabinet Price (VAT included) 2,618,000 1,925,000 1,496,000 1,386,000 1,210,000
Module Pixel Pitch (mm) 1.25 1.53 1.86 2.0 2.5
Module Resolution 256×128 208×104 172×86 160×80 128×64
Brightness (cd) 600-800
Refresh Rate (Hz) 6000
IP Rating IP30
Size 320x160
Lifespan 100,000h
Cabinet Material Aluminium
Size 640x480
Power Consumption (Max/Minimum) 178/59 178/59 135/45 135/45 140/47
GOB Module
This table provides specifications for AVAVISION's ALED display, including model name, pixel pitch (mm), pixel configuration, module size (WxHxD), module resolution, cabinet resolution, refresh rate (Hz), viewing angle (H/V), and power consumption (Max/Avg)(W).
Model Name ALED-GG12 ALED-GG15 ALED-GG18 ALED-GG20 ALED-GG25
Identifier 25652221 25652223 25652224 25652225 25652226
Cabinet Price (VAT included) 2,750,000 2,046,000 1,815,000 1,562,000 1,485,000
Module Pixel Pitch (mm) 1.25 1.53 1.86 2.0 2.5
Module Resolution 256x128 208x104 172x86 160x80 128x64
Brightness (cd) 600-800
Refresh Rate (Hz) 6000
Finishing Epoxy
IP Rating IP65
Size 320x160
Lifespan 100,000h
Cabinet Material Aluminium
Size 640x480
Power Consumption (Max/Minimum) 178/59 178/59 135/45 135/45 140/47
